Features:
(1)Data rate:155M/622M/1.25G/2.5G/4G
(2)Wavelengths:1310nm/1490nm/1550nm
(3)PIN/APD photodiode receiver
(4)SFP MSA package BIDI SC/LC
(5)+3.3V single power supply
(6)Digital Diagnostics
(7)Very low EMI and excellent ESD protection
(8)Distance from LX 10km to ZX 120km
Application:
- SONET/SDH
- Fiber Channel
Parameter | Symbol | Min. | TVP | Max. | Unit | Note |
Transmitter | ||||||
Operating Wavelength | PAVE | 1270 | 1310 | 1360 | nm | |
Ave.output power (Enabled) | -9 | -3 | dBm | 1 | ||
Extincton Ratio | ER | 9 | dB | 1 | ||
RMS spectral width | 0.65 | nm | ||||
Rise Fall tme(20%–80%) | Tr/Tf | 0.26 | ns | 2 | ||
Dispersion penalty | TDP | 3.9 | dB | |||
Output Optical Eye | Compliant with IEEE802.3z (dass 1 aser safety) |
