APPLICATIONS
· Test equipment
· Data processing networks
· LANs (Local Area Networks)
· CATV and Metro
Feature
· High precision alignment
· Compact design
· Choice of housing shape and sleeve material
Parameter
|
Unit
|
FC to E2000
|
|||
SM
|
MM
|
||||
PC
|
UPC
|
APC
|
PC
|
||
Insertion Loss (Typical)
|
dB
|
≤0.2
|
≤0.2
|
≤0.2
|
≤0.2
|
Return Loss
|
dB
|
≥45
|
≥50
|
≥60
|
≥30
|
Exchangeability
|
dB
|
≤0.2
|
|||
Repeatability
|
dB
|
≤0.2
|
|||
Durability
|
Time
|
>1000
|
|||
Operating Temperature
|
°C
|
-40~75
|
|||
Storage Temperature
|
°C
|
-45~85
|
