E2000/UPC Fiber Optical Attenuator

As a optical passive devices, attenuators mainly used in fiber optic to debug optical power performance & optical instrument calibration correction & fiber signal attenuation to ensure the optical power in a stable and desired leve in the link without any changes on its original transmission wave.

Applications:

· CATV

· Active device termination

· Telecommunication networks

· Metro

· Local Area Networks (LANs)

· Data processing networks

· Test equipment

· Precise installations

· Wide Area Networks (WANs)

Features:

· Simplex or Duplex version on request;

· UPC or APC polish available;

· Any other connector type at another side upon request;

· Fan-out on request;

· Superior quality standard PC/UPC/APC polishing;

· 100% factory test (Insertion Loss & Return Loss);

· 0.9mm, 2.0mm and 3.0mm cable optional.

Attenuation	0-30dB (Interval 1dB)
Shape	Male to female, plug type
Attenuation Accuracy	1~5dB: ±0.5dB, 6~30dB: ±10%
Housing	Plastic
Polishing	UPC, APC
Operation Wavelength	1260nm~1650nm
Operation Temperature	-40℃ ~ 75 ℃
Certification	CE/ROHS/ISO9001
Humidity Range	+/-0.2dB Change in 10% to 90% relative Humidity Range
Vibration	≤0.1dB Change between 10Hz to 55Hz

E2000/UPC Fiber Optical Attenuator
